Upgrade the Mac Pro with ease, thanks to its six PCIe Gen 4.0 slots. There are two PCIe Gen 4.0 x16 slots and four PCIe Gen 4.0 x8 slots. There is also a half-length PCIe Gen 3.0 x4 slot that is occupied by the Apple I/O card. Speaking of I/O, the Mac Pro features eight Thunderbolt 4 ports, all with 40 Gb/s data throughput and DisplayPort support. Connect to the internet via the dual 10 Gigabit Ethernet LAN jacks or go wireless with Wi-Fi 6E (802.11ax). Bluetooth 5.3 allows you to connect compatible devices wirelessly.

The Mac Pro comes with the Magic Keyboard with Touch ID and Numeric Keypad and the Magic Mouse. All you need is a display to get started. You also don't have to stop at one screen since the Mac Pro can support up to eight 4K 60 Hz displays, six 6K 60 Hz displays, or three 8K 60 Hz displays.

This Mac comes preloaded with macOS. Updates can be downloaded for free via the Mac App Store. Please check Apple's website for upgrade eligibility.

Apple M2 Ultra

The M2 Ultra is built from two M2 Max dies connected through UltraFusion, which is Apple's custom-built packaging technology. UltraFusion uses a silicon interposer that connects the dies with more than 10,000 signals, providing over 2.5 TB/s of low latency interprocessor bandwidth. UltraFusion's architecture enables the M2 Ultra to appear as a single chip to software. This means code doesn't need to be rewritten to utilize the extreme performance of the M2 Ultra.

The 24-Core CPU of the M2 Ultra consists of 16 next-gen performance cores and eight next-gen high-efficiency cores, delivering up to 20% faster performance than its predecessor, the M1 Ultra. Combined with a 76-core GPU and 192GB of unified RAM with 800 GB/s of unified memory bandwidth, this Mac Pro has the performance of not just one, but seven Afterburner cards built-in. It also features the industry-leading media engine, allowing playback of up to 22 streams of 8K ProRes video.

Expansion

Combine Apple silicon performance with the versatility of PCI expansion. The Mac Pro features six PCIe Gen 4.0 slots, which provide twice the bandwidth for audio and video I/O, networking, and storage cards. There are two double-height PCIe Gen 4.0 x16 slots, two single-height PCIe 4.0 x8 slots, and two double-height PCIe 4.0 x 8 slots. There is also a half-length PCIe 3.0 x4 slot that is occupied by the Apple I/O card.

Stacked with High-Performance I/O

The Mac Pro offers a wide array of connectivity, starting with eight Thunderbolt 4 ports, which support up to 40 Gb/s data transfer rates and DisplayPort. There are also two HDMI ports that support high-bandwidth 48 Gb/s HDMI, enabling resolutions up to 8K and refresh rates up to 240 Hz. The two USB-A ports can handle legacy USB devices while the 3.5 mm audio jack provides headphone support. There are also wireless connectivity enhancements, such as Wi-Fi 6E (802.11ax) and Bluetooth 5.3. You can also opt for a reliable, wired connection via the dual 10 Gigabit Ethernet LAN jacks.

Design

The Mac Pro maintains its unique stainless steel space frame, removable aluminum housing, and advanced thermal system. The chassis is solid and stable. And thanks to the power efficiency of Apple silicon, the Mac Pro runs even cooler and quieter under heavy workloads.

Optimized Apps

Thousands of pro apps are optimized for Apple silicon. Because macOS was designed to scale with Apple silicon, the M2 Ultra brings a huge boost in app performance and capability to the Mac Pro. And there are thousands of apps optimized to unlock the full power of Apple silicon. From rendering effects to compositing 8K scenes to analyzing enormous data sets, your go-to apps run faster and smoother than ever.

Music Production

Apple Logic Pro

Avid Pro Tools

Steinberg Cubase

Ableton Live

Video Transcoding

DaVinci Resolve Studio

Apple Compressor

Adobe Media Encoder

Topaz Video AI

Assimilate Scratch

3D Rendering

Autodesk Maya

Blender Cycles

Octane X

Maxon Redshift

Chaos V-Ray

Autodesk Arnold

Animation

Blender

Maxon Cinema 4D

SideFX Houdini

Adobe After Effects

Better for the Environment

The Mac Pro was designed with the environment in mind, including 100 percent recycled rare earth elements in all magnets, and 100 percent recycled gold plating and tin soldering in multiple printed circuit boards. The Mac Pro also uses far less energy than desktop computers in the same class, and over 40 percent less than the ENERGY STAR efficiency requirement. The Mac Pro is free of mercury, PVC, beryllium, and over 95 percent of the packaging is fiber based.

Processor	Apple M2 Ultra
GPU	Apple (76-Core)
Installed RAM	192 GB
Total Installed Storage	4 TB
Inputs/Outputs	8x USB-C (Thunderbolt 4) / Supports Video Alt Mode 3x USB-A 3.0 / 3.1/3.2 Gen 1
Display I/O	2x HDMI Output
Audio I/O	1x 1/8" / 3.5 mm Headphone Output
Wi-Fi	Wi-Fi 6 (802.11ax) with MU-MIMO Support
Bluetooth	5.3
Keyboard	Wireless Full-Size Keyboard with Number Pad
Pointing Device	Wireless Mouse
